Ton |
2 |
3 |
5 |
|||
|
Type |
ZZ1047E281AD1Y45 |
ZZ1047F341BD1Y45 |
ZZ1067F341BD165 |
|||
|
Company inner |
/K7B-0494K17D2035G |
/K7B-0494K17D2035G |
/M7B-4102K19D2442G |
|||
|
Parameters |
Overall dimension （L*W*Hmm） |
5480*2020*2450(mm) |
5995*2250*2450(mm) |
6050*2250*2450(mm) |
||
|
（L*W*H mm) |
3650*1900*400(mm) |
4200*2050*400(mm) |
4200*2050*400(mm) |
|||
|
Drive mode |
4*2 |
4*2 |
4*2 |
|||
|
Wheel base (mm) |
2800 |
3360 |
3360 |
|||
|
Wheel tread (Front/ |
1625/1525 |
1625/1525 |
1605/1545 |
|||
|
Min.ground clearance |
210mm |
210mm |
210mm |
|||
|
Front overhang/Rear |
1160/1520 |
1160/1475 |
1160/1530 |
|||
|
Approach angle(°)/Departure angle(°) |
18/18(°) |
18/18(°) |
18/18(°) |
|||
|
Max.speed(km/h) |
95 |
95 |
95 |
|||
|
Max.grade ability(%) |
30 |
30 |
30 |
|||
|
Fuel consumption |
11.8 |
11.8 |
12.4 |
|||
|
Min.turning radius(m) |
6.05 |
7 |
7 |
|||
|
Kurb weight (kg) |
2565 |
3050 |
3450 |
|||
|
Rated load(kg) |
2000 |
3000 |
5000 |
|||
|
Capacity of cab |
2 |
3 |
3 |
|||
|
Gross weight (kg) |
4695 |
6245 |
8645 |
|||
|
Cab |
width*length |
1760*1656 |
1880*1656 |
1880*1656 |
||
|
Engine |
Model |
ISF2.8s4129p |
ISF2.8s4129p |
ISF3.8s4141 |
||
|
Type |
Diesel,four-cylinder, |
Diesel,four-cylinder, |
Diesel,four-cylinder, |
|||
|
Displacement(L) |
2.8L |
2.8L |
3.8L |
|||
|
Power/rated speed |
129(96kw)/3200 |
129(96kw)/3200 |
141(105kw)/2600 |
|||
|
Maximum torque/rotate |
310/1600～2700 |
310/1600～2700 |
450/1200～2200 |
|||
|
Gear box |
Type |
WLY,5 forward & 1 |
WLY,5 forward & 1 |
WLY,6 forward & 1 |
||
|
WLY5T100 |
WLY5T100 |
WLY6T51 |
||||
|
speed ratio |
5.057 2.609 1.565 1.00 07.764 4.575® |
5.057 2.609 1.565 1.00 07.764 4.575® |
5.51 3.417 2.115 1.381 1.00 0.795 5.128® |
|||
|
Frame |
height(mm) |
170 |
170 |
195 |
||
|
Front axle |
|
VGD20QB |
VGD20QB |
VGD24QB |
||
|
Rear axle |
|
HGC35QB |
HGC35QB |
HGC42QB |
||
|
Suspension |
|
8/9+6 |
11/9+7 |
11/9+7 |
||
|
Braking system |
Drive brake |
oil brake |
air brake |
air brake |
||
|
Parking brake |
general |
general |
Cutting-off air brake |
|||
|
Auxiliary brake |
NO |
NO |
Exhaust brake(option) |
|||
|
Basic configuration |
Radio,sun shield,clutch booster,power steering,adjustable steering wheel,heater,electric control flameout,electrical heating,left hand,metallic paint of cab(except white) |
|||||
