| Item | Specification | Unit | ||
| Rated operating load | 3000 | kg | ||
| Bucket capacity | 1.5~2.5 | m³ | ||
| Machine weight | 10900±200 | kg | ||
| Dump clearance at maximum lift | 2770~3260 | mm | ||
| Reach at maximum lift | 1010~1210 | mm | ||
| Wheel base | 2900 | mm | ||
| Tread | 1850 | mm | ||
| Height of hinge at maximum lift height | 3830 | mm | ||
| Working height(fully lifted) | 4870 | mm | ||
| Max.breakout force | 130 | kN | ||
| Max.horse power | 95 | kN | ||
| Hydraulic cycle time-raise | 5.4 | s | ||
| Total hydraulic cycle time | 9.3 | s | ||
| Min. turning radius over tyres | 5170 | mm | ||
| Articulation angle | 38±1 | ° | ||
| Gradeability | 28 | ° | ||
| Tyre size | 17.5-25-12PR | |||
| Overall machine dimension L×W×H | 7245×2482×3320 | |||
| Model | WP6G125E201 | |||
| Emission standards | Emission 2 | |||
| Rated Power/Speed | 92/2200 | kW/rpm | ||
| Fuel Tank | 170 | L | ||
| Hydraulic Tank | 175 | L | ||
| Travel speed | Ⅰ-gear(F/R) | 12/16 | km/h | |
| Ⅱ-gear(F/R) | 38/- | km/h | ||
| Structure and specification are subject to change without notice.In case there is any difference between the description of the machine and the substantial machine,the substantial machine should govern. | ||||
