XCMG 16 Ton Hydraulic Vibratory Roller XP163 Pneumatic Tyred Road Roller

XCMG 16 Ton Hydraulic Vibratory Roller XP163 Pneumatic Tyred Road Roller

Item Unit XP163
Maximum operating mass kg 16000
Ground pressure kPa 150~ 300
Travel speed Gear I km/h 4
Gear II km/h 8.3
Gear II km/h 17.5
Theoretical gradeability % 20
Minimum turning radius mm 7330
Minimum ground clearance mm 260
Compaction width mm 2250
Overlapped volume of roller mm 45
Tires Specification   11.00-20
Quantity   Front 4 rear 5
Engine Type   SC4H115.4G2B
Rated power kw 86
Fuel consumption g/kw.h ≤205
Total length mm 4800
Total width mm 2356
Total height mm 3330
Diesel tank volume L 150
Water tank volume L 650
