4 Tons Diesel Powered Forklift CPCD 40F

4 Tons Diesel Powered Forklift CPCD 40F

QINGONG Engine Powered Forklift adopts diesel engine of famous foreign brand, which guarantees the power. The variable transmission system takes the high reliability mechanical gearshift or hydraulic gearshift system. The structural frame features box type, new type of door frame with good visibility, convenient and flexible hydraulic power steering. The machine is also equipped with cast rigid drive axle and plate-fin cooler. The machine is comfortable to operate and has high reliability and reliability .

MODEL

CPCD 40F

Load capacity  kg

4000

Load center  mm

500

Power type

Diesel

Max.lifting speeds(with load) mm/s

300

Max.Driving speeds(with without load) km/h

18/20

Max.Towing(with without load) kN

14.2/10.5

Gradeability(with/without load) %

16/20

Lifting height mm

3000

Free lift  mm

80

Tilting angles(forward-backward)

6/12

Min.turning radius mm

2720

Min.right angle aisle width  mm

2190

Min.under-clearance mm

135

Dimensions

Overall length mm

4100

Overall width mm

1228

Overall height(mast lowered)  mm

2110

Overall height(mast extend)  mm

4250

Overall height to overhead guard  mm

2090

Fork overhang mm

470

Wheel base mm

1900

Tread Tyre

Front tread mm

1060

Rear tread mm

1000

Front tyre

250-15

Rear tyre

6.50-10

Total weight kg

4900

Fork width mm

150

Fork thickness mm

45

Backrest height mm

1195

Fork length mm

1200

Engine

Engine model

498BPG

Rate power KW

45

Ratate Speed At Rate Power rpm

2500

Max.torque Nm

193

Rotate speed at max torque rpm

1850

Type of power shift

Clutch

Tor-Con (Hydraulic


Totop
